CM-DC

AVG-CM-DC

Installing your own motorized window coverings is now simple and convenient, with stand-alone controls and integration option offering an unparalleled experience. Elevate your space with smart and effortless control.

Note: Appropriate Gateway required for integration.



FEATURES

SPECIFICATIONS

  • Built in Receiver
  • Stall Protection
  • Preferred Stop Position
  • Manual pull sensor
  • Manual/Electronic Limit Set
  • External Control Connector
  • Compatible with External control systems using gateway
General
Model NumberAVG-CM-DC
Curtain Track Length12m Maximum
Moving Speed20cm/s
Rated Torque1.2Nm
Operating Temperature-20~65°C
Operating Humidity0~80%
Power Supply14.8V DC
Power Consumption16W
Power Cable LengthN/A
InterfaceRJ11
ButtonCoding / Setting button
Track SetSupplied as ordered
Maximal Load50Kg
Radio
Radio Protocol433.92 MHz
Signal Range(Open Field)20m
Construction
ColorWhite
Dimension420*75*50mm
Weight2kg
CasingABS, aluminum
